Manta LX TB

Manta LX TB

Heavy-duty, versatile and inexpensive machine with an extremely accurate cutting. Mainly suitable to cut masonry blocks. The head slides on two chrome-plated ground bars by means of linear ball-bearings. The cutting head is controlled by traction belts driven by a handwheel positioned by “the operator’s place”.The machine is equipped with a submersible pump placed inside the base to collect the water cooling the blade. Vertical head motion by means of a handwheel for a fast and stable adjustment. Tilting head for 45° cuts; Automatic version is also available; Angle legs.

Details



Video

Accessories

1 pump Protective screen Servicing wrenches

Optionals

Diamond cutting blade Side stop Square Side table

Download

Manta_LX_TB.pdf

Technical Data

ITEM MOD.
130204ED MANTA LX TB 120-750 MONOFASE 750 - 40 900 2,6-230 700 330 300 195x80x90 190
130200ED MANTA LX TB 120-750 TRIFASE 750 - 40 1400 4-400 700 330 320 195x80x90 190
130203ED MANTA LX TB 120-800 TRIFASE 800 - 40 1400 5,5-400 600 360 325 195x80x90 200
130202ED* MANTA LX TB 120-1000 TRIFASE 1000 - 60 900 7,5-400 550 450 400 195x80x103 270
140159 MANTA LX TB SA 120-800 TRIFASE 800 - 40 1400 5,5-400 600 360 325 195x80x90 200
140162* MANTA LX TB SA 120-1000 TRIFASE 1000 - 60 900 7,5-400 550 450 400 195x80x103 270
* No tilting head for 45° cuts.
The technical data here in mentioned are non-binding. They are for your guidance, only. NUOVA MONDIAL MEC reserves the right to modify the technical features of the machines without prior notice.
